DESIGNATED USE :

 Step less adjustment of 30 - 100 % lamp power

 Fast change between standby and full power (10 ms)

 Pulse operation

 Regulation of electric power

 Regulation of UV-intensity

ADVANTAGES

Cheaper than electronic power supply

Cheaper than multiple contact switching of chokes

Energy cost reduction

Heat reduction

Increase of effective UV-Output

Installation into existing transformer and electrical supplies at later date possible

Increase of lamp life time

Compensation of mains voltage fluctuations

Compensation of UV-intensity loss due to lamp aging processes

Integrated current monitoring with alarm contact at lamp fault

Limitation of starting current

Optimized for UV-lamps

TECHNICAL SPECIFICATIONS

Mains voltage

 230 V ±10% oder

 400 V ± 10%, 50/60 Hz

max. current

 100 A AC

max. power

 44 kVA

max. current consumption

 0.1 A AC

Control input

 0 to 10 V DC ( max. 15 V DC ) or potentiometer

Switching output

relay with zero-potential change-over contact 230 V/2A

Response time

< 20 ms (full- to part-power)

10 ms (part- to full-power)

Operation principle

phase-angle control

Weight

5.2 kg

Dimensions

193 x 180 x 200 mm (W x H x D)

Installed position

cooling ribs vertical

Ambient temperature

10 - 40 °C

Air humidity

30 - 60 %

Protection class of casing

IP 00
